Description

• Heavy-duty brass manifold with both external and internal bracing for added strength
• Durable bronze or aluminum connecting rods for enhanced reliability
• Large diameter brass or stainless steel valve caps with deeper threads for a more secure fit
• Reinforced inlet and discharge ports with a supporting ring for increased durability
• Stainless steel piston guides and check valves for smoother operation and longer life
• Heat-treated crankshaft for improved performance and resilience
• Industrial-grade tapered roller bearings for smooth, reliable movement
• Deeper back cover design to increase oil capacity for better lubrication
• 35 oz. capacity vented oil bath crankcase for optimal lubrication
• 3/4″ BSP-F inlet and 3/8″ BSP-F outlet, with a 10.0 GPM flow rate and above requiring 3/4″ BSP-F inlet and 1/2″ BSP-F outlet
• Maximum fluid temperature: 160°F

MAX FLOW 10.0 GPM / 38.0 L/MIN
MAX PRESSURE 2900 PSI / 200 BAR
RATED PUMP SPEED 1450 RPM
POWER REQUIREMENT 19.5 HP ELECTRIC
LUBRICATION 34.5 OZ UDOR LUBE

See Spec sheet Here UDORCKC3820
